QH fine small

Function type	QH-05type	QH-10type	QH-16type	QH-25type	QH-50type	QH-100type	QH-200type
Power Supply	AC220V 50/60HZ(If AC24V、AC110V、AC380V、DC240V、DC220V Please explain when ordering the power supply)
Moment	50N.M	100N.M	160N.M	250N.M	500N.M	1000N.M	2000N.M
*Time（S）	5、10、30	5、15、30、60	5、15、30、60	5、15、30、60	5、15、30、60	60	100
Electric machinery	15W/H	23W/H	23W/H	50W/H	90W/H	100W/H	100W/H
Working current	0.25A	0.6A	0.7A	0.8A	1.2A	1.3A	1.3A
Weight	2.5Kg	3.7Kg	3.7Kg	6.8Kg	8.0Kg	12Kg	12Kg
*Rotation angle	0°~360°	0°~90°
Ambient temperature	-30℃~+60℃
Withstand voltage	1500VAC/1Minute
Protection level	IP-67
Limit	Electrical machinery
Manual operation	Attached handle
Installation angle	Arbitrary angle
